| Carriage Type | Twin |
| Center Height | 0.877" |
| For Shaft Type | Round |
| Housing Material Name | Aluminum Alloy |
| Mount Hole Center To Center Length | 3" |
| Mount Hole Center To Center Width | 2 1/8" |
| Mounting Hole Dia. | 3/16" |
| Overall Height | 1 13/32" |
| Resistance Properties | Corrosion Resistance |
| Shaft Center To Mount Hole Width | 1 1/16" |
| System Of Measurement | Metric |
| Bearing Material | Aluminum Alloy |
| Dynamic Load Rating | 4448.22N |
| For Shaft Diameter | 16 mm |
| Lubrication | Grease Lubrication |
| Mounting Bolt Size | #8 |
| Mounting Hole Diameter | 0.1875" |
| Overall Length | 101.6 mm |
| Overall Width | 63.5 mm |
| Pillow Block Type | Standard |
| Standards | ISO |
| Ship weight (kg) | 0.54 |
| Ship height (cm) | 3.57 |
| Ship length (cm) | 10.16 |
| Ship width (cm) | 6.35 |
| Country of Origin | US |
