| Motor Type | Stepper Motor |
| Nut Drag Torque | 0.025 N-m to 0.031 N-m |
| Nut Material | Stainless Steel |
| Nut Shape | Round |
| Phase | 2 |
| Screw Material | Stainless Steel |
| Screw Type | Lead Screw |
| Step Accuracy | -5% to +5% |
| Steps Per Revolution | 200 |
| Thread Direction | Right |
| Assembly Type | Lead Screw Assembly |
| Coating Material | PTFE |
| Electrical Connection | Plug In Connector |
| Frame | NEMA 23 |
| Insulation Class | Class B |
| Insulation Resistance | 100 M ohms |
| Lead Accuracy | 0.003 in./ft. |
| Lead Length | 5 mm |
| Left End Components | None |
| Motor Ip Rating | IP40 |
| Motor Length | 79 mm |
| Motor Maximum Operating Temperature | 50°C |
| Motor Minimum Operating Temperature | -20°C |
| Motor Operating Temperature Range | -20°C to 50°C |
| Motor Size | NEMA 23 |
| Nut Bolt Circle Diameter | 44.5 mm |
| Nut Diameter | 20.3 mm |
| Nut Dynamic Load Capacity | 1040N |
| Nut Flange Diameter | 54 mm |
| Nut Flange Thickness | 6.4 mm |
| Nut Length | 49.5 mm |
| Nut Mounting Hole Diameter | 5.6 mm |
| Nut Type | Anti-Backlash |
| Percent Efficiency | 55% |
| Rated Current | 3A |
| Right End Components | None |
| Screw Diameter | 16 mm |
| Screw Length | 400 mm |
| Screw Material Grade | Grade 300 |
| Travel Per Step | 0.025 mm |
| Winding Resistance | 1.1 ohms |
| Ship weight (kg) | 1.35 |
| Country of Origin | US |
