| Bearing Type | Plain |
| Carriage Type | Plain Bearing |
| Cover Type | No Cover |
| Lubricant | Petroleum Based Grease |
| Lubrication | Petroleum Based Grease |
| Motor Type | Stepper Motor |
| Number Of Carriages Included | 1 |
| Rail System Type | Gliding Surface Rail |
| Bearing Load Capacity | 240N |
| Bearing Type | Plain |
| Carriage Bearing Moment Load Capacity | 15.1 N-m (Mx), 9 N-m (My), 9 N-m (Mz) |
| Carriage Length | 50.8 mm |
| Carriage Type | Plain Bearing |
| Carriage Width | 45 mm |
| Cover Type | No Cover |
| Drive Input Speed | 2000 RPM |
| Lead | 6 mm |
| Lubricant | Petroleum Based Grease |
| Maximum Acceleration | 50 m/sq. sec. |
| Motor Mount Option | NEMA 17 Single Stack |
| Motor Type | Stepper Motor |
| Number Of Carriages Included | 1 |
| Nut Type | Anti-Backlash |
| Overall Height | 64 mm |
| Rail Length | 80 mm |
| Rail System Type | Gliding Surface Rail |
| Repeatability | 0.02 mm |
| Screw Diameter | 6 mm |
| Stroke Length | 10 mm |
| Travel Speed | 4200 mm/sec. |
| Voltage Rating | 24V |
| Ship weight (kg) | 0.68 |
| Ship height (cm) | 6.4 |
| Country of Origin | US |
