| Bearing Load Capacity | 2500N |
| Bearing Type | Ball |
| Carriage Bearing Moment Load Capacity | 13.1 N-m (My), 13.1 N-m (Mz), 20.2 N-m (Mx) |
| Carriage Length | 60 mm |
| Carriage Type | Profile Rail |
| Carriage Width | 60 mm |
| Cover Type | Tall |
| Drive End Option | PBC Linear Integrated Motor Screw |
| Drive Input Speed | 3000 RPM |
| Lead | 10 mm |
| Lubricant | Oil Based Lithium Soap Grease |
| Maximum Acceleration | 50 m/sq. sec. |
| Motor Mount Option | NEMA 17 Single Stack |
| Motor Type | Stepper Motor |
| Number Of Carriages Included | 1 |
| Nut Type | Anti-Backlash |
| Overall Height | 67.8 mm |
| Rail Length | 130 mm |
| Rail System Type | Profile Rail |
| Repeatability | 0.02 mm |
| Screw Diameter | 10 mm |
| Stroke Length | 10 mm |
| Travel Speed | 4200 mm/sec. |
| Voltage Rating | 24V |
| Ship weight (kg) | 1.35 |
| Ship height (cm) | 6.78 |
| Country of Origin | US |
