| Item | Female Elbow |
| Application | Air |
| Color | Silver |
| Compatible Tube Material | Nylon |
| Fitting Side A Connection Type | Push To Connect |
| Fitting Side A Tube Outer Dia. | 3/8" |
| Fitting Side A Tube Outer Diameter | 3/8" |
| Fitting Side B Connection Type | FNPT |
| Fitting Side B Pipe Size | 1/4" |
| Gasket Material | Buna N |
| Includes Pre-applied Thread Sealant | No |
| Length | 1 1/4" , 1.062" |
| Material | Brass |
| Max. Operating Pressure | 250 psi |
| Max. Operating Temp. | 200°F |
| Min. Operating Temp. | 40°F |
| Outside Dia. | 3/8" |
| Overall Length | 1 1/16" |
| Pipe Size | 1/4" |
| Release Ring Material | Buna N |
| Release Type | Button |
| Resistance Properties | Impact Resistant |
| Specific Fitting Angle | 90° |
| Specific Fitting Shape | Elbow Adapter |
| System Of Measurement | Imperial |
| Thread Size | 1/4" |
| Tube Outside Dia. | 3/8" |
| Tube Size | 3/8" |
| Ship weight (kg) | 0.09 |
| Ship height (cm) | 0.95 |
| Ship length (cm) | 2.7 |
| Ship width (cm) | 2.54 |
| Country of Origin | US |
