| Air Inlet Size | 3/8" |
| Air Outlet Size | 3/8" |
| Body Material | Zinc |
| Bowl Size | 4.4 oz. |
| Bowl Size - Air Treatment | 4.4 oz. |
| Depth | 2 3/4" |
| Differential Pressure Indicator Included | No |
| Drain Included | Yes |
| Drain Port Size | 1/8" |
| Drain Type | Automatic |
| Duty Rating | Heavy Duty |
| Filter Bowl Capacity | 4.4 oz. |
| Filter Bowl Guard Included | Yes |
| Filter Bowl Guard Material | Steel |
| Filter Bowl Material | Plastic |
| Filter Element Material | Plastic |
| Filter Media | Polypropylene |
| Filter Rating | 40 µm |
| For Fluid Type | Oil, Water |
| For Removal Of | Particles, Water |
| For Substance Type | Liquid Water, Oil, Particles |
| Gauge Included | No |
| Height | 6 1/4" |
| Housing Material | Die Cast Zinc |
| Includes | Air Filter, Auto Float Drain, Metal Bowl Guard, Polycarbonate Bowl |
| Max. Flow Rate | 80 CFM |
| Max. Incoming Pressure | 150 psi |
| Max. Operating Pressure | 150 psi |
| Max. Pressure | 150 psig |
| Modular Connection | Modular Connection |
| Number Of Air Inlets | 1 |
| Number Of Air Outlets | 1 |
| Pressure Drop | 5 psig |
| Seal Material | Nitrile |
| Size - Air Treatment | Compact |
| System Location | Air Line |
| Type | Particulate |
| Width | 2 13/16" |
| Air Inlet Type | NPT |
| Air Outlet Type | NPT |
| Connection Style | Air Line |
| Drain Part Compatbility | PS506P |
| Filter Type | Particulate |
| Maximum Flow Rate | 80 CFM |
| Maximum Operating Pressure | 150 psi |
| Maximum Operating Temperature | 125°F |
| Minimum Operating Temperature | 32°F |
| Overall Depth | 2 3/4" |
| Overall Height | 6 1/4" |
| Overall Width | 2 13/16" |
| Series | 06F Series |
| Weight | 1.4 lbs. |
| Ship weight (kg) | 0.9 |
| Ship height (cm) | 15.88 |
| Ship length (cm) | 6.99 |
| Ship width (cm) | 7.14 |
| Country of Origin | US |
