| Item | Tap |
| 55% Thread Drill Size | 9.1 mm |
| 65% Thread Drill Size | 8.9 mm |
| 75% Thread Drill Size | 8.9 mm |
| Coolant Fed | Non Coolant Through |
| Cutting Direction - Machining | Right Hand |
| Extended Neck | Yes |
| Extended Shank | Yes |
| Finish | Vaporized |
| Grade | Grade 16355 |
| List Number | 16355 |
| No. Of Pieces | 1 |
| Number Of Flutes | 0 |
| Overall Length | 150 mm |
| Primary Material Application | Aluminum, Hardened Steel, Stainless Steel, Steel |
| Primary Material Application Iso Code | H, M, N, P |
| Secondary Material Application | Nickel, Titanium |
| Secondary Material Application Iso Code | S |
| Shank Dia. | 9.67 mm |
| Shank Length | 111 mm |
| Spiral Direction | Neutral |
| Square Size | 7.2 mm |
| System Of Measurement | Metric |
| Tap Chamfer | Modified Bottoming |
| Tap Length Standard | DIN |
| Tap Material | Cobalt |
| Tap Shank Standard | DIN |
| Tap Thread Type | Metric Fine |
| Tap Type | Thread Forming |
| Thread Direction | Right Hand |
| Thread Length | 15 mm |
| Thread Limit | D9 |
| Thread Pitch | 1.25 mm |
| Thread Size | M10 x 1.25 |
| Thread Standard | Metric Fine |
| Material Grade - Machining | Grade 16355 |
| Measurement System | Metric |
| Standards | DIN |
| Tap Finish | V |
| Tap Style | Thread Forming |
| Tap Thread Size | M10 x 1.25 |
| Ship weight (kg) | 0.08 |
| Product | Model | Price | |
|---|---|---|---|
 |
1294600 | €89.22 | |
 |
1764501 | €79.13 | |
|
1764601 | €80.12 | |
 |
1625510226 | €168.81 | |
|
1625510426 | €120.79 | |
 |
1652501108 | €113.45 | |
 |
1767101 | €122.66 |
