| Item | Tap |
| 55% Thread Drill Size | 13.25 mm |
| 65% Thread Drill Size | 0.516" |
| 75% Thread Drill Size | 12.9 mm |
| Coolant Fed | Non Coolant Through |
| Cutting Direction - Machining | Right Hand |
| Extended Neck | No |
| Extended Shank | Yes |
| Finish | Vaporized |
| Fits Class | Class 4H |
| List Number | 16255 |
| No. Of Pieces | 1 |
| Number Of Flutes | 0 |
| Overall Length | 7.078" |
| Primary Material Application | Aluminum, Brass, Bronze, Copper, Hardened Steel, Stainless Steel, Steel |
| Primary Material Application Iso Code | H, M, N, P |
| Secondary Material Application | Nickel, Titanium |
| Secondary Material Application Iso Code | S |
| Shank Dia. | 0.422" |
| Shank Length | 5 7/64" |
| Spiral Direction | Neutral |
| Square Size | 0.322" |
| System Of Measurement | Fractional Inch |
| Tap Chamfer | Modified Bottoming |
| Tap Length Standard | DIN |
| Tap Material | Cobalt |
| Tap Shank Standard | DIN |
| Tap Type | Forming , Thread Forming |
| Thread Direction | Right Hand |
| Thread Length | 53/64" |
| Thread Limit | H7 |
| Thread Size | 9/16"-18 |
| Threads Per Inch | 18 |
| Class Of Fit | Class 4H |
| Material Grade - Machining | Grade 16255 |
| Measurement System | Fractional Inch |
| Standards | DIN |
| Tap Finish | V |
| Tap Style | Thread Forming |
| Tap Thread Size | 9/16"-18 |
| Thread Standard | UNF |
| Ship weight (kg) | 0.14 |
| Product | Model | Price | |
|---|---|---|---|
 |
1294600 | €89.22 | |
 |
1764501 | €79.13 | |
|
1764601 | €80.12 | |
 |
1625510226 | €168.81 | |
|
1625510426 | €120.79 | |
 |
1652501108 | €113.45 | |
 |
1767101 | €122.66 |
