| Item | Thread Forming Tap |
| Coolant Fed | Non-Coolant Through |
| Cutting Direction - Machining | Right Hand |
| Features | Produces No Chips |
| Finish | TiCN |
| List Number | 16250 |
| Material | Cobalt |
| No. Of Pieces | 1 |
| Number Of Flutes | 3 |
| Overall Length | 3.938" |
| Pitch Diameter Limits | H8 |
| Primary Material Application | Aluminum, Brass, Bronze, Copper, Hardened Steel, Stainless Steel, Steel |
| Primary Material Application Iso Code | H, M, N, P |
| Secondary Material Application | Hardened Steel, Nickel, Titanium |
| Secondary Material Application Iso Code | H, S |
| Shank Dia. | 0.242" |
| Spiral Direction | Neutral |
| Square Size | 0.242" |
| Tap Chamfer | Modified Bottoming |
| Tap Grouping | Tap |
| Tap Type | Thread Forming |
| Thread Direction | Right Hand |
| Thread Length | 1 7/16" |
| Thread Type | Coarse |
| 55% Thread Drill Size | 10.4 mm |
| 65% Thread Drill Size | 10.3 mm |
| 75% Thread Drill Size | 10.2 mm |
| Class Of Fit | Class 2B |
| Extended Neck | Yes |
| Material Grade - Machining | Grade 16250 |
| Shank Length | 2 7/32" |
| Standards | DIN |
| Tap Finish | TiCN |
| Tap Length Standard | DIN |
| Tap Material | Cobalt |
| Tap Shank Standard | ANSI |
| Tap Style | Thread Forming |
| Thread Limit | H8 |
| Thread Limit / Class Of Fit | H8, 2B |
| Thread Size | 7/16"-14 |
| Thread Standard | UNC |
| Threads Per Inch | 14 |
| Ship weight (kg) | 0.06 |
| Ship height (cm) | 1.91 |
| Ship length (cm) | 10.16 |
| Ship width (cm) | 1.91 |
| HS code | 8207504060 |
| Product | Model | List Number | Overall Length | Pitch | Shank Dia. | Size | Thread Length | Thread Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
1605012208 | 16050 | 100mm | 20 | 0.367" | 1/2" | 1 21/32" | UNF | €203.52 |
