| Item | Miniature Snap Action Switch |
| Actuation Type | Long Hinge Lever |
| Actuator Length | 2.01" |
| Amps Rating | 10A |
| Body Material | Thermoplastic |
| Contact Form | SPDT |
| Depth | 0.406" |
| Differential Travel | 0.079" |
| Height | 5/8" |
| Length | 1.09" |
| Max. Pretravel | 0.355" |
| Mounting Dimension | 0.875" |
| Operating Force | 0.72 oz. |
| Operating Temp. | -13°F to +185°F |
| Over Travel | 0.118" |
| Release Force | 0.24 oz. |
| Terminal Type | Quick Connect |
| Voltage | 0.5V AC |
| Ac Contact Rating | 10A @ 240V |
| Actuator Style | Hinge Lever |
| Body Depth | 0.41" |
| Body Height | 0.62" |
| Body Width | 1.09" |
| Center Mounting Hole Distance | 0.87" |
| Differential Travel - Maximum | 0.079" |
| Display Qty | 1 |
| Electrical Connection | Quick Connect |
| Lever Actuator Length | 2.01" |
| Operating Force - Maximum | 0.72 ozf |
| Operating Temperature - Maximum | 185°F |
| Operating Temperature - Minimum | -13°F |
| Overall Depth | 0.41" |
| Overall Height | 0.62" |
| Overall Width | 1.09" |
| Pre-travel | 0.355" |
| Standards | CE, CSA, UL LISTED |
| Ship weight (kg) | 0.01 |
| Ship height (cm) | 1.27 |
| Ship length (cm) | 7.62 |
| Ship width (cm) | 2.79 |
| HS code | 8536509040 |
| Country of Origin | CN |
| Product | Model | Actuator Length | Current Rating | Differential Travel | Max. Pretravel | Operating Force | Operating Temp. Range | Over Travel | Release Force | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
V-10G2 | 27.4 +/-0.8 mm | 10A | 0.76mm | 0.125" | 1.31 oz. | -40 Degrees to 150 Degrees C | 0.085" | 0.25 oz. | €4.73 | |
 |
V-15G6-D | 1" | 15A | 0.031" | 0.126" | 4.41 oz. | -13 Degrees to 185 Degrees F | 0.087" | 1.16 oz. | €6.32 | |
 |
V-15G-D | 1" | 15A | 0.012" | 0.047" | 7.05 oz. | -13 Degrees to 185 Degrees F | 0.051" | 2.32 oz. | €3.84 |
