| Item | Bearing |
| Application | Agriculture, Automotive, Cosmetic/Pharmaceutical, Food Processing, Industrial Machinery, Machine Tools, Material Handling, Refinery/Petrochemical |
| Back Side To Center Width | 1.142" |
| Bore Dia. | 2.438" |
| Bore Type | Cylindrical |
| Closure Type | Double Sealed |
| Dynamic Load Capacity | 9220 lbf. |
| Flange Thickness | 0.781" |
| Grade | Grade 440C |
| Housing Material | Stainless Steel |
| Housing Material Finish | Unfinished |
| Housing Material Grade | Grade 440C |
| Housing Type | Square |
| Included Bearing | SUC212-39FG1 |
| Included Bearing Cap | Open Cap |
| Includes | (2) Set Screw |
| Insert Material | Stainless Steel |
| Insert Type | Radial Ball |
| Lubricant Material Grade | FDA/USDA-H1 Solid Grease |
| Lubrication Openings | None |
| Max. Speed | 1900 RPM |
| Max. Temp. | 250°F |
| Min. Temp. | -20°F |
| Mount Hole Center-to-center Height | 5 5/8" |
| Mount Hole Center-to-center Length | 5 5/8" |
| Mount Hole Size | 0.748" |
| Mounting Bolt Size | 5/8" |
| Number Of Mounting Holes | 4 |
| Overall Height | 6.891" |
| Overall Length | 6.891" |
| Overall Width | 2.703" |
| Resistance Properties | Corrosion Resistant |
| Rolling Element Rows | 1 |
| Seal Material | Silicone |
| Seal Type | Contact |
| Shaft Locking Type | Set Screws |
| Static Radial Load Capacity | 7080 lbf. |
| Sub-brand | Sentinel |
| Bearing Insert Material | Stainless Steel |
| Bearing Insert Type | Radial Ball |
| Bearing Material Grade | 440C |
| Bore Diameter | 2 7/16" |
| Closure | Double Sealed |
| Expansion Type | Fixed |
| Lubricant Material | FDA, USDA-H1 Solid Grease |
| Maximum Speed | 1900 RPM |
| Maximum Temperature | 250°F |
| Minimum Temperature | -20°F |
| Number Of Mount Holes | 4 |
| Standards | NSF H1 REGISTERED |
| Ship weight (kg) | 5.45 |
| Ship height (cm) | 17.5 |
| Ship length (cm) | 17.5 |
| Ship width (cm) | 6.87 |
| Product | Model | Price | |
|---|---|---|---|
 |
SUCNFL208-24C0FG1 | €722.05 | |
 |
SUCFL208-24C0FG1 | €955.47 | |
|
SUCNFL206-20C0FG1 | €479.73 | |
 |
SUCNFL206-20CCFG1 | €538.63 | |
|
SUCNFL207-20C0FG1 | €626.31 | |
 |
SUCFL207-20CCFG1 | €916.34 | |
|
SUCFL207-20C0FG1 | €862.92 |
