| Item | Flange |
| Application | Potable Water |
| Bolt Hole Dia. | 5/8" |
| Bolt Hole Diameter | 5/8" |
| Compatible Tube Material | Copper |
| Fitting Material | Copper |
| Fitting Side A Connection Type | Cup |
| Fitting Side A Copper Tube Size | 1 1/4" |
| Fitting Side A Tube Outer Diameter | 1 1/4" |
| Fitting Side B Connection Type | Flange |
| Flange O.d. | 4 5/8" |
| Flange Thickness | 9/16" |
| Flannge Outside Dia. | 4 5/8" |
| No. Of Bolt Holes | 4 |
| Number Of Bolt Holes | 4 |
| Specific Fitting Shape | Flange Adapter |
| Flange Outside Diameter | 4 5/8" |
| Standards | ASME/ANSI B16.22, MSS SP-104, NSF/ANSI/CAN-61 |
| Ship weight (kg) | 1.09 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
| Country of Origin | US |
| Product | Model | Item | Max. Pressure | Outside Dia. | Tube Size | Price | |
|---|---|---|---|---|---|---|---|
 |
741 1 | Flange | 105 psi@100 Degrees F | 1.125" | 1" | €59.25 | |
|
741 2 | Flange | 100 psi@100 Degrees F | 2.125" | 2" | €143.76 | |
|
741 3 | Flange | 95 psi@100 Degrees F | 3.125" | 3" | €192.42 | |
|
741 1 1/4 | Flange | 105 psi@100 Degrees F | 1.375" | 1.25" | €62.98 | |
|
741 1 1/2 | Flange | 100 psi@100 Degrees F | 1.625" | 1.5" | €105.65 | |
 |
741 2 1/2 | Flange | 100 psi@100 Degrees F | 2.625" | 2.5" | €186.11 | |
 |
K355490 | Flange | - | - | - | €70.99 |
