| Item | Drop Elbow, 90 Degrees |
| Application | Air, Non-Potable Water |
| Basic Pipe Fitting Material | Metal |
| Basic Pipe Fitting Shape | Elbow |
| Body Material | Cast Bronze |
| Fitting Material | Cast Bronze |
| Fitting Side A Connection Type | Cup |
| Fitting Side A Copper Tube Size | 3/4" |
| Fitting Side A Tube Outer Dia. | 7/8" |
| Fitting Side B Connection Type | Cup |
| Fitting Side B Copper Tube Size | 3/4" |
| Fitting Side B Tube Outer Dia. | 7/8" |
| Max. Pressure | 466 psi |
| Outside Dia. | 7/8" |
| Size | 3/4" |
| Temp. Range | -20°F to +400°F |
| Fitting Side A Tube Outer Diameter | 7/8" |
| Fitting Side B Tube Outer Diameter | 7/8" |
| Material Grade | C84400 |
| Maximum Operating Pressure | 466 psi @ 200°F |
| Maximum Operating Temperature | 400°F |
| Minimum Operating Temperature | 20°F |
| Resistance Properties | Dezincification Resistant |
| Specific Fitting Shape | Drop Ear 90° Elbow |
| Standards | ASME B16.18, ASTM B584 ALLOY C84400, ISO 9001 |
| Ship weight (kg) | 0.11 |
| Ship height (cm) | 3.81 |
| Ship length (cm) | 4.83 |
| Ship width (cm) | 5.84 |
| HS code | 7412200085 |
| Country of Origin | US |
