| Item | Indexable Chamfer Mill |
| Cutting Application | Chamfering, Facing, Turning |
| Cutting Direction | Right Hand |
| For Use With | 50-1100 |
| Includes | 16-1020, 16-1060 |
| Insert Holding Type | Screw On |
| No. Of Pieces | 2 |
| Number Of Pieces | 2 |
| Offset Shank | Yes |
| Overall Length | 2 1/2" |
| Shank | Square |
| Shank Dia. | 0.312" |
| Shank Material | High Speed Steel |
| Side-to-cutting Tip | 0.394" |
| Ansi Code | SCKCR 0505 D2 |
| Approach Angle | 75° |
| Features | 75°Facing and Chamfering Holder Utilizing 100° Unused Left Hand Cutting Edge of Insert |
| Insert Clearance Angle | 7° |
| Insert Shape | 80° Diamond |
| Iso Number | SCKCR 0505 D2 |
| Shank Height | 5/16" |
| Shank Width | 5/16" |
| Toolholder Style | SCKC |
| Ship weight (kg) | 0.05 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 12.07 |
| Ship width (cm) | 2.54 |
| HS code | 8466100175 |
| Country of Origin | IN |
