| Connection Size | 1/2" |
| Connection Type | NPT |
| For Pipe Size | 1/2" |
| Height | 4 2/5" |
| Includes | Switch |
| Length | 3 4/5" |
| Max. Media Temp. | 225°F |
| Max. Pressure | 100 psi |
| Media Temp. Range | +32°F to +225°F |
| Min. Ambient Temp. | 32°F |
| Min. Media Temp. | 32°F |
| Overall Height | 4 2/5" |
| Overall Width | 3 4/5" |
| Series | FS1 Series |
| Switch Type | SPDT |
| Type | Electrically Operated, General Purpose |
| Voltage | 120/240V AC |
| Wetted Material | Brass, EPDM |
| Width | 3 4/5" |
| Connection | 1/2" NPT |
| Contact Rating (ac) | 22.2A @ 240V (Locked Rotor), 3.7A @ 240V (Full Load), 44.4A @ 120V (Locked Rotor), 7.4A @ 120V (Full Load) |
| Media Temperature (maximum) | 225°F |
| Media Temperature (minimum) | 32°F |
| Overall Length | 3.8" |
| Standards | CE, CSA CERTIFIED, UL LISTED |
| Ship weight (kg) | 1.35 |
| Ship height (cm) | 21.34 |
| Ship length (cm) | 8.64 |
| Ship width (cm) | 7.62 |
| Country of Origin | US |
