MARTIN SPROCKET E80C60 Sprocket, Stock Bore, 60 Teeth, 19.107 Inch Pitch Dia., 19.681 Inch O.D., Steel
Get it by Tuesday, Jun 17
€1,578.47 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Roller Chain Sprocket |
| Bore Type | Rough Bore |
| Chain Number | 80 |
| Chain Pitch | 1" |
| Construction | Welded With Lightening Holes |
| Finished Bore Size | 1 1/2" |
| For Chain Number | 80 |
| For Chain Pitch | 1" |
| Hub Configuration | C |
| Hub Outside Dia. | 6 1/4" |
| Individually Packaged | No |
| Length Through Bore | 4 3/4" |
| Material | Steel |
| Max. Bore Size | 4 1/4" |
| Min. Bore Size | 1 1/4" |
| Number Of Chain Rows | 3 |
| Number Of Teeth | 60 |
| Outside Dia. | 19.681" |
| Pitch Dia. | 19.1073" |
| Single Strand Tooth Thickness | 0.557" |
| Storage Dimension Height | 4 3/4" |
| Storage Dimension Length | 19.681" |
| Storage Dimension Width | 19.681" |
| Weight | 128 lbs. |
| Ship weight (kg) | 57.6 |
| Ship height (cm) | 12.07 |
| Ship length (cm) | 49.99 |
| Ship width (cm) | 49.99 |
