MARTIN SPROCKET E40B14H Sprocket, Stock Bore, 40 Chain, 14 Teeth, 2.247 Inch Pitch Dia., 2.491 Inch O.D., Steel
Get it by Tuesday, Jun 17
€133.39 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Roller Chain Sprocket |
| Bore Type | Finished Bore |
| Chain Number | 40 |
| Chain Pitch | 1/2" |
| Construction | Solid |
| Finished Bore Size | 1/2" |
| For Chain Number | 40 |
| For Chain Pitch | 1/2" |
| Hardened Teeth | 1 |
| Hub Configuration | B |
| Hub Outside Dia. | 1 11/16" |
| Individually Packaged | Yes |
| Length Through Bore | 2 1/8" |
| Material | Steel |
| Max. Bore Size | 1 1/8" |
| Min. Bore Size | 1/2" |
| Number Of Chain Rows | 3 |
| Number Of Teeth | 14 |
| Outside Dia. | 2.491" |
| Pitch Dia. | 2.247" |
| Single Strand Tooth Thickness | 0.275" |
| Storage Dimension Height | 2 1/8" |
| Storage Dimension Length | 2 5/8" |
| Storage Dimension Width | 2 5/8" |
| Ship weight (kg) | 0.68 |
| Ship height (cm) | 5.4 |
| Ship length (cm) | 6.32 |
| Ship width (cm) | 6.32 |
