MARTIN SPROCKET E35B16H Sprocket, 35 Chain, 16 Teeth, 1.922 Inch Pitch Dia., 2.110 Inch O.D., Steel
Get it by Tuesday, Jun 17
€100.49 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Roller Chain Sprocket |
| Bore Type | Finished Bore |
| Chain Number | 35 |
| Chain Pitch | 3/8" |
| Construction | Solid |
| Finished Bore Size | 1/2" |
| For Chain Number | 35 |
| For Chain Pitch | 3/8" |
| Hardened Teeth | 1 |
| Hub Configuration | B |
| Hub Outside Dia. | 1.4688" |
| Individually Packaged | Yes |
| Length Through Bore | 1 3/4" |
| Material | Steel |
| Max. Bore Size | 15/16" |
| Min. Bore Size | 1/2" |
| Number Of Chain Rows | 3 |
| Number Of Teeth | 16 |
| Outside Dia. | 2.11" |
| Pitch Dia. | 1.9222" |
| Single Strand Tooth Thickness | 0.162" |
| Storage Dimension Height | 2" |
| Storage Dimension Length | 2 5/16" |
| Storage Dimension Width | 2 5/16" |
| Weight | 0.9 lbs. |
| Ship weight (kg) | 0.37 |
| Ship height (cm) | 4.45 |
| Ship length (cm) | 5.36 |
| Ship width (cm) | 5.36 |
