MARTIN SPROCKET DS50ATB18H Sprocket, Taper, 50 Chain, 18 Teeth, 3.599 Inch Pitch Dia., 3.920 Inch O.D., Steel
Get it by Tuesday, Jun 17
€262.50 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Roller Chain Sprocket |
| Bore Type | Bushed Bore |
| Bushing Part Number | 1615 |
| Chain Number | 50 |
| Chain Pitch | 5/8" |
| Construction | Solid |
| For Chain Number | 50 |
| For Chain Pitch | 5/8" |
| Hardened Teeth | 1 |
| Hub Configuration | A |
| Individually Packaged | Yes |
| Length Through Bore | 1.656" |
| Material | Steel |
| Max. Bore Size | 1 5/8" |
| Min. Bore Size | 1/2" |
| Number Of Chain Rows | 2 |
| Number Of Teeth | 18 |
| Outside Dia. | 3 23/25" |
| Pitch Dia. | 3.5992" |
| Single Strand Tooth Thickness | 0.343" |
| Storage Dimension Height | 1 11/16" |
| Storage Dimension Length | 4 1/16" |
| Storage Dimension Width | 4 1/16" |
| Weight | 1.84 lbs. |
| Ship weight (kg) | 0.83 |
| Ship height (cm) | 4.22 |
| Ship length (cm) | 9.96 |
| Ship width (cm) | 9.96 |
| Product | Model | Price | |
|---|---|---|---|
 |
DS50ATB16H | €195.04 | |
 |
DS50ATB17H | €210.64 | |
 |
DS50ATB19H | €231.66 | |
 |
DS50ATB20H | €233.65 | |
 |
DS50ATB21H | €236.86 | |
 |
DS50ATB23H | €242.06 | |
 |
DS50ATB24H | €250.14 |
