MARTIN SPROCKET D35B12H Sprocket, 35 Chain, 12 Teeth, 1.449 Inch Pitch Dia., 1.625 Inch O.D., Steel
Get it by Tuesday, Jun 17
€69.73 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Roller Chain Sprocket |
| Bore Type | Finished Bore |
| Chain Number | 35 |
| Chain Pitch | 3/8" |
| Construction | Solid With Recess Groove |
| Finished Bore Size | 1/2" |
| For Chain Number | 35 |
| For Chain Pitch | 3/8" |
| Hardened Teeth | 1 |
| Hub Configuration | B |
| Hub Outside Dia. | 1 1/4" |
| Hub Recessed For Chain | 1 |
| Individually Packaged | Yes |
| Length Through Bore | 1 1/4" |
| Material | Steel |
| Max. Bore Size | 9/16" |
| Min. Bore Size | 1/2" |
| Number Of Chain Rows | 2 |
| Number Of Teeth | 12 |
| Outside Dia. | 1 5/8" |
| Pitch Dia. | 1.4489" |
| Single Strand Tooth Thickness | 0.162" |
| Storage Dimension Height | 1 5/16" |
| Storage Dimension Length | 2 1/8" |
| Storage Dimension Width | 2 1/8" |
| Ship weight (kg) | 0.14 |
| Ship height (cm) | 3.18 |
| Ship length (cm) | 4.14 |
| Ship width (cm) | 4.14 |
