MARTIN SPROCKET 80R41 Sprocket, 80 Chain, 41 Teeth, 13.064 Inch Pitch Dia., 13.625 Inch O.D., Steel
Get it by Tuesday, Jun 17
€372.94 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Roller Chain Sprocket |
| Bore Type | Bushed Bore |
| Bushing Part Number | R1 |
| Chain Number | 80 |
| Chain Pitch | 1" |
| Construction | Welded |
| For Chain Number | 80 |
| For Chain Pitch | 1" |
| Hub Configuration | B |
| Hub Outside Dia. | 5 1/2" |
| Individually Packaged | No |
| Keyway Size | 3/4" |
| Length Through Bore | 2" |
| Material | Steel |
| Max. Bore Size | 3 3/4" |
| Min. Bore Size | 1 1/8" |
| Number Of Chain Rows | 1 |
| Number Of Teeth | 41 |
| Outside Dia. | 13 5/8" |
| Pitch Dia. | 13.0635" |
| Single Strand Tooth Thickness | 0.575" |
| Storage Dimension Height | 2" |
| Storage Dimension Length | 13 5/8" |
| Storage Dimension Width | 13 5/8" |
| Weight | 23.2 lbs. |
| Ship weight (kg) | 10.3 |
| Ship height (cm) | 5.08 |
| Ship length (cm) | 34.62 |
| Ship width (cm) | 34.62 |
