| Item | Roller Chain Sprocket |
| Bore Type | Finished Bore |
| Chain Number | 2062 |
| Chain Pitch | 1 1/2" |
| Construction | Solid |
| Finished Bore Size | 15/16" |
| For Chain Number | 2062 |
| For Chain Pitch | 1 1/2" |
| Hub Configuration | A |
| Individually Packaged | No |
| Length Through Bore | 0.433" |
| Material | Steel |
| Min. Bore Size | 15/16" |
| Number Of Chain Rows | 1 |
| Number Of Teeth | 18 |
| Outside Dia. | 9.41" |
| Pitch Dia. | 8.6382" |
| Single Strand Tooth Thickness | 0.459" |
| Storage Dimension Height | 0.459" |
| Storage Dimension Length | 9.41" |
| Storage Dimension Width | 9.41" |
| Weight | 6.6 lbs. |
| Ship weight (kg) | 3.13 |
| Ship height (cm) | 1.17 |
| Ship length (cm) | 23.9 |
| Ship width (cm) | 23.9 |
