MARTIN SPROCKET 160E12H Sprocket, QD, 160 Chain, 12 Teeth, 7.727 Inch Pitch Dia., 8.664 Inch O.D., Steel
Get it by Friday, Jun 13
€572.71 /unit
Add To Cart
Request a Quote
Payment
Get it by Friday, Jun 13
Payment
| Item | Roller Chain Sprocket |
| Bore Type | Bushed Bore |
| Bushing Part Number | E |
| Chain Number | 160 |
| Chain Pitch | 2" |
| Construction | Solid |
| For Chain Number | 160 |
| For Chain Pitch | 2" |
| Hardened Teeth | 1 |
| Hub Configuration | B |
| Hub Outside Dia. | 5.807" |
| Individually Packaged | No |
| Length Through Bore | 1 5/8" |
| Material | Steel |
| Max. Bore Size | 3 5/16" |
| Min. Bore Size | 7/8" |
| Number Of Chain Rows | 1 |
| Number Of Teeth | 12 |
| Outside Dia. | 8.664" |
| Pitch Dia. | 7.7274" |
| Single Strand Tooth Thickness | 1.156" |
| Storage Dimension Height | 1.62" |
| Storage Dimension Length | 8.664" |
| Storage Dimension Width | 8.664" |
| Weight | 11.69 lbs. |
| Ship weight (kg) | 5.26 |
| Ship height (cm) | 4.11 |
| Ship length (cm) | 22 |
| Ship width (cm) | 22 |
