MARTIN SPROCKET 100B14SS Roller Chain Sprocket, 100 Chain, 14 Teeth, 5.618 Inch Pitch Dia., 6.227 Inch O.D., SS
Get it by Tuesday, Jun 17
€1,264.26 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Roller Chain Sprocket |
| Bore Type | Finished Bore |
| Chain Number | 100 |
| Chain Pitch | 1 1/4" |
| Construction | Solid |
| Finished Bore Size | 1 1/4" |
| For Chain Number | 100 |
| For Chain Pitch | 1 1/4" |
| Hub Configuration | B |
| Hub Outside Dia. | 4 3/16" |
| Individually Packaged | No |
| Length Through Bore | 1 5/8" |
| Material | Stainless Steel |
| Max. Bore Size | 2.502" |
| Min. Bore Size | 1 1/4" |
| Number Of Chain Rows | 1 |
| Number Of Teeth | 14 |
| Outside Dia. | 6.227" |
| Pitch Dia. | 5.618" |
| Single Strand Tooth Thickness | 0.692" |
| Storage Dimension Height | 1 5/8" |
| Storage Dimension Length | 6.631" |
| Storage Dimension Width | 6.631" |
| Weight | 7.4 lbs. |
| Ship weight (kg) | 3.33 |
| Ship height (cm) | 4.14 |
| Ship length (cm) | 15.82 |
| Ship width (cm) | 15.82 |
