| Item | Ballast |
| Amps Ac | 0.72/0.36/0.31A |
| Ballast Bulb Type | T8 |
| Ballast Factor | 0.85 |
| Ballast Type | Electronic |
| Dimming | Yes |
| Dimming Method | Proprietary |
| Dimming Range | 10% to 100% |
| Dimming Type | Full Continuous Dimming |
| Height | 1" |
| Includes | Power And Lamp Leads |
| Input Voltage | 120-277V AC |
| Input Watts | 85/84/86 W |
| Length | 9 1/2" |
| Max. Bulb Watts | 32 W |
| Min. Starting Temp. | 50°F |
| Number Of Bulbs Supported | 3 |
| Number Of F32t8 Lamps | 3 |
| Operating Amps @ 120v | 0.72A |
| Power Factor | Greater Than 0.95 |
| Sockets Included | No |
| Start Type | Programmed/Rapid |
| Starter Required | No |
| Thermal Protection | Class P |
| Total Harmonic Distortion | Less Than 10% |
| Width | 2 3/8" |
| Wiring Type | Parallel |
| Ballast Start Type | Rapid |
| Brand And Series | EcoSystem |
| Bulb Wattage | 32 W |
| Frequency | 50/60 Hz |
| Lamp Types Supported | (3) F32T8 |
| Number Of Lamps Supported | 3 |
| Overall Height | 1" |
| Overall Length | 9 1/2" |
| Overall Width | 2 3/8" |
| Product Type | Fluorescent Ballast |
| Standards | ANSI C62.41, ANSI C82.11, ANSI/ESD S20.20, CSA CERTIFIED, ISO 9001:2008, S MARK CERTIFIED, UL LISTED |
| Total Harmonic Distortion - Maximum | 10% |
| Ship weight (kg) | 0.49 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 24.13 |
| Ship width (cm) | 6.03 |
| Country of Origin | MX |
| Product | Model | Item | Price | |
|---|---|---|---|---|
 |
EC5NST554CU210R | Ballast | - | RFQ
|
 |
EC5NST528CU210R | Ballast | - | RFQ
|
 |
H3DT825CU110 | Ballast | - | RFQ
|
 |
EC5T528JUNV1 | Ballast | €377.89 | |
 |
EHDT832MU117 | Ballast | - | RFQ
|
 |
H3DT832CU110 | Ballast | - | RFQ
|
 |
H3DT832CU117 | Ballast | - | RFQ
|
