LEESON LM34065 SRD4B1T65 200-575 Volt Motor | AJ2WMD SRD4B1T65

LEESON LM34065 SRD4B1T65 200-575 Volt Motor

In Stock
Item: AJ2WMD Model: LM34065Cross Ref: SRD4B1T65

Get it by Jun 7, Friday

Not eligible for flat shipping. Flat shipping is available on order value €99,00 or more and aggregate weight below 10 pounds.

€188.48 /unit
Add To Cart
Request a Quote

Payment Methods

Delivery Partners

Product Specifications:

Item200-575 Volt Motor
CodeM
DesignB
DutyContinuous
EnclosureDP
Frame56
Full Load Amps1.2
HP1
Hz60
Insulation ClassF
kW0.75
LubricationPolyrex EM
Max. Ambient Temp.40
MountingRigid
PackagingF
Phase3
Power Factor56.1
RotationREV
RPM1800
Service Factor1.15
TypeTS
Voltage575

Shipping Info:

Ship weight (kg) 13.5
Ship height (cm)21.92
Ship length (cm)39.7
Ship width (cm)21.92

Product Details:

  • Supersedes Leeson - LM25059 / SRD4S1T65
  • S. F Amps: 1.4
  • Eff 100%: 83.5
  • Bearing OPE: 6203
  • CC Number: EXEMPT
  • Bearing PE: 6203
  • Nameplate: 10000419-001-001
  • Winding: SS0070160
  • GROUP: 3
  • Paint: GRAY - LINCOLN

Product Variants

ProductModelMax. Ambient Temp.RPMFull Load AmpsPower FactorHPService FactorInsulation ClasskWPrice
LEESON LM34062 SRD4B0.5T65 200-575 Volt Motor | AJ2WMA SRD4B0.5T65 LM340624018000.755.51/21.25B0.37€151.41
LEESON LM34064 SRD2B1T65 200-575 Volt Motor | AJ2WMC SRD2B1T65 LM340645036001.264.311.0F0.75€75.21
LEESON LM34068 SRD2B2T65 200-575 Volt Motor | AJ2WMG SRD2B2T65 LM340684036002.262.621.15F1.49€845.29
