LEESON LM25135 SRN6H0.25TC61 Definite Purpose Motor

In Stock
Item: AJ2WDV Model: LM25135Cross Ref: SRN6H0.25TC61

Get it by May 24, Friday

Not eligible for flat shipping. Flat shipping is available on order value €99,00 or more and aggregate weight below 10 pounds.

€171.25 /unit
Add To Cart
Request a Quote

Payment Methods

Delivery Partners

Product Specifications:

ItemDefinite Purpose Motor
CodeM
DesignB
DutyContinuous
EnclosureTENV
Frame56C
Full Load Amps1.2 / .6
HP1/4
Hz60
Insulation ClassF
kW.187
LubricationPolyrex EM
Max. Ambient Temp.65
MountingRigid
PackagingB
Phase3
Power Factor50
RotationREV
RPM1200
Service Factor1.0
TypeTS
Voltage230 / 460

Shipping Info:

Ship weight (kg) 10.8
Ship height (cm)20.62
Ship length (cm)41.61
Ship width (cm)26.67

Product Details:

  • Eff 100%: 72
  • Bearing OPE: 203
  • CC Number: EXEMPT
  • Bearing PE: 203
  • Winding: ZT6113
  • GROUP: 3
  • Paint: GRAY (POWDER)

Product Variants

ProductModelFull Load AmpsHPkWMax. Ambient Temp.Power FactorRPMService FactorPrice
LEESON LM25153 SRN2H0.33TC61 Definite Purpose Motor | AJ2WEA SRN2H0.33TC61 LM251532 / 11/3.2464052.936001.15€134.30
