LEESON LM24788 SS145A2S3TZ1B66L14MB6TP2 Agricultural Motor, 3 HP, 1 Phase, 60 Hz, 230V, 3600 RPM
Get it by Tuesday, Jun 17
€218.54 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Code | H |
| Duty Cycle | Continuous |
| Enclosure Type | Totally Enclosed Air Over |
| Frame | 145TZ |
| Full Load Amps | 11.8A |
| Insulation Class | Class F |
| Motor Shaft Rotation | Selective Counter Clockwise |
| Motor Type | BTR |
| Mounting Type | Rigid Base |
| Nema Design | H |
| Packaging | B |
| Phase | 1 |
| Power | 2.24 kW |
| Power Factor | 99.2 |
| Rpm | 3600 RPM |
| Service Factor | 1 |
| Shaft Dia. | 7/8" |
| Thermal Protection | Automatic |
| Voltage | 230V AC |
| Ship weight (kg) | 20.7 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 41.61 |
| Ship width (cm) | 26.67 |
| Country of Origin | MX |
| Product | Model | Frame | Full Load Amps | HP | kW | Power Factor | Type | Voltage | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
LM24787 | 143TZ | 16.8 / 8.4 | 1.5 | 1.12 | 79 | CTR | 115 / 230 | €641.29 |
