LEESON 5KH39QN9514X 4309 / 5KH39QN9514BX Fan and Blower Motor, 0.33 HP, 1 Phase, 60 Hz, 230V, 1800 RPM
Get it by Tuesday, Jun 17
€383.37 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Duty Cycle | Continuous |
| Enclosure Type | Dripproof |
| Frame | 48 |
| Frequency | 60 Hz |
| Full Load Amps | 3.1A |
| Hp | 1/3 hp |
| Insulation Class | Class B |
| Max. Ambient Temp. | 40°C |
| Motor Enclosure Design | Dripproof |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Rigid Base |
| Motor Shaft Rotation | CCW |
| Motor Thermal Protection | Automatic |
| Motor Type | Split Phase |
| Mounting Type | Resilient Base |
| Nameplate Rpm | 1725 RPM |
| Number Of Speeds | 1 |
| Phase | 1 |
| Service Factor | 1.35 |
| Shaft Dia. | 1/2" |
| Shaft Length | 1 1/2" |
| Shaft Orientation | Horizontal/Vertical |
| Thermal Protection | Automatic |
| Voltage | 230V AC |
| Ship weight (kg) | 6.75 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 34.77 |
| Ship width (cm) | 18.11 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Enclosure | Frame | Full Load Amps | HP | kW | Mounting | Orientation | Rotation | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
048S17D2017 | DP | 48 | 3.6 | 1/6 | 0.13 | Resilient Base | Horizontal | SELECTIVE CCW | €249.41 | |
 |
5KH39QN5512T | Open | 48Y | 5.1 | 1/4 | - | RB | Horizontal or Vertical | Counterclockwise | €210.52 | |
 |
5KH32FN3083 | DP | 48Z | 5.1 | 1/4 | - | RB | Horizontal or Vertical | Counterclockwise | €254.35 | |
 |
5KH32HN5620T | Open | 48Y | 6.6 | 1/3 | - | RB | Horizontal or Vertical | Clockwise | €245.08 | |
 |
048S17D2086 | DP | 48 | 6.1 | 1/3 | 0.25 | Resilient Base | Horizontal | SELECTIVE CCW | €250.03 | |
 |
5KH35MNA519T | Open | 48Y | 7.9 | 1/2 | - | RB | Horizontal or Vertical | Clockwise | €330.28 | |
 |
5KH32JN3128 | DP | 48Z | 6.2 | 1/3 | - | RB | Horizontal or Vertical | Counterclockwise | €293.24 |
