LEESON 5K49PN3052 K280 Fan and Blower Motor, .75,.25 HP, 3 Phase, 60 Hz, 460V, 1800 RPM
Get it by Tuesday, Jun 17
€748.84 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Design | B |
| Duty Cycle | Continuous |
| Enclosure Type | Dripproof |
| Frame | 56 |
| Frequency | 60 Hz |
| Full Load Amps | 1.3/0.7A |
| Hp | 3 1/4 hp |
| Insulation Class | Class B |
| Max. Ambient Temp. | 40°C |
| Motor Enclosure Design | Dripproof |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Rigid Base |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | No |
| Motor Type | Three Phase |
| Mounting Type | Resilient Base |
| Nameplate Rpm | 1725/1140 RPM |
| Nema Design | B |
| Phase | 3 |
| Rpm | 1725/1140 RPM |
| Service Factor | 1.25 |
| Shaft Dia. | 0.63" |
| Shaft Length | 1 22/25" |
| Shaft Orientation | Horizontal/Vertical |
| Thermal Protection | None |
| Voltage | 460V AC |
| Ship weight (kg) | 12.6 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 34.77 |
| Ship width (cm) | 18.11 |
| HS code | 8501514040 |
| Country of Origin | MX |
| Product | Model | Frame | Full Load Amps | HP | Hz | kW | Mounting | Orientation | RPM | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5K49PN4088X | 56H | 5.1-5.2/2.6 | 1.5 | 60 | - | RB | Horizontal or Vertical | 1725 | €622.91 | |
 |
5K49UN4086X | 56H | 6.2-6.0/3.0 | 2 | 60 | - | RB | Horizontal or Vertical | 1725 | €679.08 | |
 |
5K46KN4085 | 56 | 3.3-3.0/1.5 | 3/4 | 50/60 | - | RB | Horizontal or Vertical | 1725/1425 | €483.39 | |
 |
056T17D5350 | 56HZ | 9.2-8.6/4.3 | 3 | 60 | 2.24 | Resilient Base | Horizontal | 1800 | €755.64 | |
 |
056T17D2104 | 56 | 1.5-1.6/.8 | 1/3 | 60 | 0.25 | Resilient Base | Horizontal | 1800 | €461.16 | |
 |
056T17D2101 | 56 | 3.4-3.4/1.7 | 1 | 60 | 0.75 | Resilient Base | Horizontal | 1800 | €571.67 | |
 |
056T17D5347 | 56 | 3.5-3.6/1.8 | 1 | 60 | 0.75 | Resilient Base | Horizontal | 1800 | €595.12 |
