LEESON 5K49MN6081 K541 Fan and Blower Motor, 0.50 HP, 3 Phase, 60 Hz, 208-230/460V, 1200 RPM
Get it by Tuesday, Jun 17
€847.00 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Bearing Type | Ball |
| Body Dia. | 6.438" |
| Duty Cycle | Continuous |
| Enclosure Type | Totally Enclosed Fan Cooled |
| Frame | 56 |
| Frequency | 60 Hz |
| Full Load Amps | 1.3/2.6A |
| Full Load Efficiency | 72% |
| Hp | 1/2 hp |
| Insulation Class | Class B |
| Length Less Shaft | 9.688" |
| Motor Application | HVAC/R |
| Motor Frame Material | Steel |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Cradle |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Sub Application | Belt Drive Fan/Blower |
| Motor Thermal Protection | No |
| Motor Type | Three Phase |
| Mounting Type | Resilient Base |
| Number Of Speeds | 1 |
| Overall Length | 11.562" |
| Phase | 3 |
| Resilient Ring Dia. | 2 1/4" |
| Ring To Ring Center | 7.938" |
| Rpm | 1140 RPM |
| Rpm Range | 1101-1200 RPM |
| Service Factor | 1 |
| Shaft Dia. | 0.63" |
| Shaft Length | 1 22/25" |
| Shaft Orientation | Horizontal/Vertical |
| Thermal Protection | None |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 208-230/460V AC |
| Warranty | 1 yr. |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Manufacturers Warranty Length | 1 yr. |
| Max. Ambient Temp. | 104°F |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Service Factor | 1 |
| Nameplate Rpm | 1140 RPM |
| No. Of Speeds | 1 |
| Nominal Efficiency | 72% |
| Standards | CSA (MC236833), UL (E46035) |
| Weight | 27 lbs. |
| Ship weight (kg) | 12.15 |
| Ship height (cm) | 24.13 |
| Ship length (cm) | 38.46 |
| Ship width (cm) | 25.88 |
| HS code | 8501514040 |
| Country of Origin | MX |
| Product | Model | Enclosure | Frame | Full Load Amps | HP | NEMA Design | RPM | Service Factor | Voltage | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5K49KN4142 | TENV | 56 | 3.3-3.0/1.5 | 3/4 | M | 1725 | 1.0 | 208-230/460 | €630.93 | |
 |
5K49MN6080 | TENV | 56 | 2.6-2.6/1.3 | 1/2 | B | 1140 | 1.0 | 208-230/460 | €784.04 | |
 |
5K33KN52 | TENV | 48 | 1.5/0.8 | 1/3 | - | 1725 | 1.35 | 230/460 | €521.66 | |
 |
5K42HN4128 | TENV | 56 | 2.3-2.2/1.1 | 1/2 | B | 1725 | 1.0 | 208-230/460 | €584.62 |
