LEESON 5K49KN4563 K457 Brake Motor, 0.50 HP, 3 Phase, 60 Hz, 230/460V, 1800 RPM
Get it by Tuesday, Jun 17
€1,118.63 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Brake Motor |
| Ambient Temp. | 40°C |
| Assembly | F1 Only |
| Bearing Protection | Double Shield |
| Brake Model/series | Series 56000 |
| Brake Rating | 3 lbs.-ft. |
| Break-down Torque | 97.8 lbs.-ft. |
| Conduit Box Location | Exterior |
| Conduit Box Position | F1 Only |
| Design | B |
| Duty Cycle | Continuous |
| Frame | 56C |
| Frequency | 60 Hz |
| Full Load Amps | 0.9A |
| Hp | 1/2 hp |
| Includes | Key |
| Insulation Class | Class B |
| Inverter Rated | No |
| Length Less Shaft | 12 1/8" |
| Max. Ambient Temp. | 40°C |
| Motor Application | Brake Motor |
| Motor Bearings | Ball |
| Motor Enclosure Design | Totally Enclosed Non Ventilated |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | C Face Footless |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | Thermostat |
| Motor Type | Squirrel Cage Induction Run |
| Mounting | Rigid Base |
| Mounting Type | C Face, Footless |
| Nameplate Rpm | 1725 RPM |
| Nema Design | B |
| Nominal Efficiency | 78.5% |
| Number Of Speeds | 1 |
| Orientation | Horizontal |
| Output Kw | 0.37 kW |
| Overall Length | 14.062" |
| Phase | 3 |
| Power | 0.37 kW |
| Rpm Range | 1701-1800 RPM |
| Service Factor | 1 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1.938" |
| Torque | 3 lbs.-ft. |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 208-230/460V AC |
| Warranty | 18 Months |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Manufacturers Warranty Length | 18 Months |
| Motor Design | 3-Phase |
| Motor Service Factor | 1 |
| No. Of Speeds | 1 |
| Standards | CSA, UL RECOGNIZED |
| Weight | 29 lbs. |
| Ship weight (kg) | 13.05 |
| Ship height (cm) | 27.64 |
| Ship length (cm) | 49.53 |
| Ship width (cm) | 26.52 |
| HS code | 8501514040 |
| Country of Origin | US |
| Product | Model | Assembly | Full Load Amps | HP | kW | Mounting | Orientation | Torque | Voltage | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5K49PN4565 | NAN | 2.5/1.25 | 3/4 | 0.55 | C Face | NAN | 6 | 230/460 | €1,312.49 |
