| Item | Single Phase Motor |
| Ambient Temp. | 104°F |
| Base Type | Rigid Base |
| Bearing Type | Ball |
| Code | L |
| Duty Cycle | Continuous |
| Efficiency | 66% |
| Frame | 48 |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 7/3.4-3.5A |
| Hp | 1/2 hp |
| Insulation Class | Class B |
| Motor Application | General Application |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Position | Horizontal |
| Motor Shaft Rotation | Selective Counter Clockwise |
| Motor Type | Capacitor Start |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 3600 RPM |
| Nema Design | L, N |
| No. Of Speeds | 1 |
| Output Kw | 0.37 kW |
| Overall Length | 9 5/16" |
| Packaging | B |
| Phase | 1 |
| Power Factor | 68 |
| Rpm Range | 3001-3600 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 1/2" |
| Shaft Length | 1 1/2" |
| Thermal Protection | None |
| Type | CF |
| Usable @ 208v | Yes |
| Voltage | 115/208-230V AC |
| Ship weight (kg) | 8.55 |
| Ship height (cm) | 22.23 |
| Ship length (cm) | 34.93 |
| Ship width (cm) | 20.02 |
| Country of Origin | MX |
