| Item | DC Motor |
| Amps | 5A |
| Duty Cycle | Continuous |
| Efficiency | 81.4% |
| Form Factor | 1.38 |
| Frame | 56C |
| Hp | 1/2 hp |
| Insulation Class | Class F |
| Lubrication | Polyrex EM |
| Max. Ambient Temp. | 40°C |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Shaft Rotation | Reversible |
| Mounting Type | C Face, Footless |
| Nameplate Rpm | 1750 RPM |
| Packaging | PG659201.04B |
| Service Factor | 1 |
| Shaft Dia. | 5/8" |
| Torque | 18 lbs.-in. |
| Type | DF |
| Voltage | 90V DC |
| Ship weight (kg) | 11.25 |
| Ship height (cm) | 27.64 |
| Ship length (cm) | 36.68 |
| Ship width (cm) | 26.52 |
| Country of Origin | US |
