| Item | Metric Motor |
| Bearing Type | Ball |
| Cc Number | CC003A |
| Duty Cycle | Continuous |
| Efficiency Group | Premium |
| Enclosure Type | Totally Enclosed Fan Cooled |
| Frame | 90L |
| Frame Material | Aluminum |
| Frequency | 50/60 Hz |
| Full Load Amps | 5.4/2.7A |
| Hp | 2 hp |
| Insulation Class | Class F |
| Inverter Rated | Yes |
| Length | 326 mm |
| Length Less Shaft | 276 mm |
| Max. Ambient Temp. | 40°C |
| Motor Application | General Application |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | No |
| Motor Type | Squirrel Cage Inverter Rated |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 1745 RPM |
| Nominal Efficiency | 86.5% |
| Number | CC003A |
| Number Of Speeds | 1 |
| Phase | 3 |
| Power | 1.49 kW |
| Rpm Range | 1701-1800 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 24 mm |
| Shaft Length | 50 mm |
| Thermal Protection | None |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 230/460V AC |
| Full Load Amps @ 50hz | 5.4/2.7A |
| Hp @ 50hz | 2 hp |
| Hz | 50/60 Hz |
| Ins. Class | Class F |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Frame Material | Aluminum |
| Motor Service Factor | 1.15 |
| No. Of Speeds | 1 |
| Overall Length | 326 mm |
| Standards | CE, CSA, UL RECOGNIZED |
| Weight | 44 lbs. |
| Ship weight (kg) | 19.8 |
| Ship height (cm) | 27 |
| Ship length (cm) | 39.5 |
| Ship width (cm) | 24.51 |
| HS code | 8501524000 |
| Country of Origin | CN |
| Product | Model | Frame | Full Load Amps | HP | Hz | kW | RPM | Price | |
|---|---|---|---|---|---|---|---|---|---|
 |
071T17FH5408 | 71 | 1.8/0.9 | 1/2 | 60 | 0.37 | 1800 | €444.41 | |
 |
090LT34FH6420 | 90L | 7.2/3.6 | 3 | 60 | 2.24 | 3600 | €1,046.12 | |
 |
063T17FH5402 | 63 | 1.0/0.5 | 1/4 | 60 | 0.18 | 1800 | €374.49 |
