LEESON 056T34F99017 D394A / 56T34F99017A AC Induction Motor, General Purpose, Inverter Rated And 4-In-1, 1-1/2Hp, 3-Phase
Get it by Tuesday, Jun 17
€713.04 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | AC Motor |
| Ambient Temperature | 40 °C |
| Assembly/box Mounting | F1 ONLY |
| Ce | Y |
| Csa | Y |
| Current | 4/2 & 3.4/1.7 A |
| Design Code | B |
| Drive End Bearing | Ball |
| Drive End Bearing Size | 6203 |
| Duty | Continuous |
| Efficiency | 84 & 85.5 % |
| Electrical Type | Squirrel Cage Induction Run |
| Enclosure | Totally Enclosed Fan Cooled |
| Frame | 56C |
| Frame Length | 8.06 in |
| Frame Material | Rolled Steel |
| Frequency | 60 & 50 Hz |
| Insulation Class | F |
| Ip Code | 43 |
| Kva Code | M |
| Motor Orientation | Horizontal |
| Mounting | Bolt-on Base |
| Number Of Speeds | 1 |
| Opp Drive End Bearing | Ball |
| Opp Drive End Bearing Size | 6203 |
| Output Hp | 1.50 & 1 Hp |
| Output Kw | 1.1 & 0.75 kW |
| Overall Length | 13.31 in |
| Phase | 3 |
| Poles | 2 |
| Power Factor | 83.5 |
| Resistance Main | 9.27 Ohms |
| Rotation | Reversible |
| Service Factor | 1.15 & 1.15 |
| Shaft Diameter | 0.625 in |
| Shaft Extension | 2.06 in |
| Shaft Type | NEMA 56 |
| Speed | 3450 & 2850 rpm |
| Starting Method | Across The Line |
| Thermal Protection | No Protection |
| Ul | Recognized |
| Voltage | 230/460 & 190/380 V |
| Ship weight (kg) | 11.7 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 40.94 |
| Ship width (cm) | 26.04 |
| Country of Origin | MX |
| Product | Model | Price | |
|---|---|---|---|
 |
145TTFR16331 | €837.74 | |
 |
056T34F99020 | €713.04 | RFQ
|
