LEESON 056T17F5349 D452 / 56T17F5349A Brake Motor, 0.50/0.33 HP, 3 Phase, 60/50 Hz, 208-230/460 and 190/380V, 1800 and 1500 RPM
Get it by Tuesday, Jun 17
€1,117.40 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Brake Motor |
| Ambient Temp. | 40°C |
| Application | Brake Motor |
| Bearing Type | Ball |
| Brake Model/series | Series 56, Series 87 |
| Brake Rating | 25 lbs.-ft. |
| Break-down Torque | 7.2 lbs.-ft. |
| Conduit Box Location | Exterior |
| Conduit Box Position | F1 Only |
| Duty Cycle | Continuous |
| Frame | 56C |
| Frame Material | Rolled Steel |
| Frequency | 50/60 Hz |
| Full Load Amps | 2.3-2.4/1.2A |
| Hp | 1/2 hp |
| Insulation Class | Class B |
| Length Less Shaft | 14.188" |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | No |
| Motor Type | Three Phase |
| Mounting Type | Face |
| Nameplate Rpm | 1725 RPM |
| Nominal Efficiency | 72.1% |
| Number Of Speeds | 1 |
| Overall Length | 16 1/4" |
| Phase | 3 |
| Rpm Range | 1701-1800 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2 1/16" |
| Thermal Protection | None |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 208-230/460V AC |
| Hz | 50/60 Hz |
| Ins. Class | Class B |
| Max. Ambient Temp. | 40°C |
| Motor Application | Brake Motor |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Service Factor | 1.15 |
| No. Of Speeds | 1 |
| Standards | CE, CSA, UL RECOGNIZED |
| Weight | 30 lbs. |
| Ship weight (kg) | 13.5 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 50.5 |
| Ship width (cm) | 26.04 |
| HS code | 8501514040 |
| Country of Origin | MX |
| Product | Model | Full Load Amps | HP | Length Less Shaft | Nominal Efficiency | Price | |
|---|---|---|---|---|---|---|---|
 |
056T17F5348 | 1.5-1.6/0.8 | 1/3 | 13 11/16" | 68 | €993.93 |
