LEESON 056T17F15677 56T17F15677A / D457A Brake Motor, 1.50 and 1 HP, 3 Phase, 60/50 Hz, 230/460 and 190/380V, 1800 and 1500 RPM
Get it by Friday, Jun 13
€1,746.61 /unit
Add To Cart
Request a Quote
Payment
Get it by Friday, Jun 13
Payment
| Item | Brake Motor |
| Ambient Temp. | 40°C |
| Bearing Protection | Double Seal Full Contact |
| Bearing Type | Ball |
| Brake Rating | 10 lbs.-ft. |
| Conduit Box Location | Exterior |
| Conduit Box Position | F1 |
| Duty Cycle | Continuous |
| Frame | 56HC |
| Frame Material | Steel |
| Frequency | 50/60 Hz |
| Full Load Amps | 2.3A |
| Hp | 1 1/2 hp |
| Includes | Key |
| Inverter Rated | No |
| Length Less Shaft | 16 7/8" |
| Motor Application | Brake Motor |
| Motor Mounting Position | Horizontal |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
| Motor Type | Three Phase |
| Mounting Type | Rigid Base |
| No. Of Speeds | 1 |
| Nominal Efficiency | 86.5% |
| Overall Length | 18 11/16" |
| Phase | 3 |
| Rpm Range | 1701-1800 RPM |
| Series | Series 56000 |
| Service Factor | 1.15 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1 7/8" |
| Thermal Protection | None |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 230/460V AC |
| Brake Model/series | Series 56000 |
| Hz | 50/60 Hz |
| Ins. Class | Class B |
| Manufacturers Warranty Length | 18 Months |
| Max. Ambient Temp. | 40°C |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Frame Material | Steel |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1.15 |
| Motor Thermal Protection | No Protection |
| Nameplate Rpm | 1725 RPM |
| Standards | CE, CSA, UL RECOGNIZED |
| Weight | 58 lbs. |
| Ship weight (kg) | 26.1 |
| Ship height (cm) | 35.56 |
| Ship length (cm) | 56.36 |
| Ship width (cm) | 41.91 |
| Country of Origin | MX |
