LEESON 056T17E5308 G646 / 56T17E5308E Explosion Proof Motor, 0.25 HP, 3 Phase, 60 Hz, 230/460 V, 1800 RPM
Get it by Tuesday, Jun 17
€898.24 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Explosion Proof Motor |
| Ambient Temp. | 40°C |
| Assembly | F1 Only |
| Bearing Type | Ball |
| Conduit Box Location | Exterior |
| Conduit Box Position | F1 Only |
| Duty Cycle | Continuous |
| Efficiency | 75% |
| Enclosure Type | Explosion Proof Non Ventilated |
| Frame | 56 |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Hazardous Location Class | 1 C, D, 2 F, G , EXP PROOF CL I GR C&, D CL II GR F&, G T3B |
| Hazardous Location Division | Division 1 |
| Hp | 1/4 hp |
| Includes | Explosion Proof Conduit Box |
| Insulation Class | Class B |
| Length Less Shaft | 10" |
| Max. Ambient Temp. | 40°C |
| Motor Application | Hazardous Location |
| Motor Enclosure Design | Totally Enclosed Non Ventilated |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | Automatic |
| Motor Type | Three Phase |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 1725 RPM , 1800 RPM |
| Nema Design | B |
| Nominal Efficiency | 75% |
| Number Of Speeds | 1 |
| Orientation | Horizontal |
| Output Rating | 0.187 kW |
| Overall Length | 12" |
| Phase | 3 |
| Power | 0.187 kW |
| Service Factor | 1 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2" |
| Temp. Code | T3B |
| Thermal Protection | Automatic |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 208-230/460V |
| Full Load Amps | 1.10-1.1/0.55A |
| Hz | 60 |
| Ins. Class | Class B |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Frame Material | Steel |
| Motor Service Factor | 1 |
| No. Of Speeds | 1 |
| Standards | CSA CERTIFIED, UL LISTED |
| Weight | 28 lbs. |
| Ship weight (kg) | 11.25 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 41.61 |
| Ship width (cm) | 26.67 |
| HS code | 8501514040 |
| Country of Origin | MX |
| Product | Model | Enclosure | Frame | Full Load Amps | Hazardous Location Class | HP | Insulation Class | Item | kW | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
143TTGR16026 | Totally Enclosed Fan-Cooled | 143T | 3.3-3.3/1.65 | 1 C,D / 2 E,F,G | 1 | B | Hazardous Location Motor | - | €1,312.49 | |
 |
145TTGR16040 | Totally Enclosed Fan-Cooled | 145T | 6.2-6/3 | 1 C,D / 2 E,F,G | 2 | F | Hazardous Location Motor | - | €1,520.53 | |
 |
056T17G5313 | EPFC | 56 | 2.9-3/1.5 | EXP PROOF CL I GR C&D CL II GR F&G T3B | 3/4 | B | Explosion Proof Motor | 0.56 | €1,067.39 | |
 |
056T17E5309 | EPNV | 56 | 1.2-1.2/.6 | EXP PROOF CL I GR C&D CL II GR F&G T3B | 1/3 | B | Explosion Proof Motor | 0.246 | €955.04 | |
 |
056T17G5321 | EPFC | 56 | 0.95 | EXP PROOF CL I GR C&D CL II GR F&G T3B | 1/2 | B | Explosion Proof Motor | 0.37 | €1,009.98 | |
 |
056T17E5315 | EPNV | 56 | 0.5 | EXP PROOF CL I GR C&D CL II GR F&G T3B | 1/3 | B | Explosion Proof Motor | 0.25 | €954.42 | |
 |
056T17G5312 | EPFC | 56 | 2.3-2.4/1.2 | EXP PROOF CL I GR C&D CL II GR F&G T3B | 1/2 | B | Explosion Proof Motor | 0.37 | €1,011.21 |
