LEESON 056T11D5209 X235 / 56T11D5209E Motor, 1 HP, 3 Phase, 60 Hz, 200-230/460V, 1200 RPM
Get it by Friday, Jun 13
€772.92 /unit
Add To Cart
Request a Quote
Payment
Get it by Friday, Jun 13
Payment
| Item | OEM Replacement Motor |
| Application | Fans And Blowers |
| Bearing Type | Ball |
| Body Dia. | 7 1/16" |
| Capacitor Required | No |
| Conduit Box Location | Exterior |
| Conduit Box Position | F1 Only |
| Duty Cycle | Continuous |
| Frame | 56 |
| Frequency | 60 Hz |
| Full Load Amps | 6-6.6/3A |
| Hp | 1 hp |
| Length Less Shaft | 12 7/8" |
| Max. Ambient Temp. | 70°C |
| Motor Application | Direct Drive Fan/Blower |
| Motor Design | Three Phase |
| Motor Enclosure Design | Open Air Over |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal |
| Motor Shaft Rotation | CW/CCW |
| Motor Sub Application | Direct Drive Fan/Blower |
| Motor Thermal Protection | Automatic |
| Mounting Type | Band |
| Nameplate Rpm | 1140 RPM |
| No. Of Speeds | 1 |
| Number Of Shafts | 1 |
| Number Of Speeds | 1 |
| Oem Replacement Brand | Carrier, Marathon |
| Overall Length | 14 13/16" |
| Phase | 3 |
| Replacement For | 56T11D33, HD52VE214 |
| Rpm Range | 0-1000 RPM |
| Service Factor | 1 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1 15/16" |
| Stud Size | #10-32 |
| Thermal Protection | Automatic |
| Thread Fit | Class 2A |
| Thread Type | Fine |
| Usable @ 200v | Yes |
| Usable @ 208v | Yes |
| Voltage | 200-230/460V AC |
| Ins. Class | Class B |
| Motor Bearings | Ball |
| Motor Mounting Type | Band |
| Motor Service Factor | 1 |
| Standards | CSA, UL |
| Weight | 36 lbs. |
| Ship weight (kg) | 16.2 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 41.61 |
| Ship width (cm) | 26.67 |
| HS code | 8501516040 |
| Country of Origin | MX |
| Product | Model | Body Dia. | Frame | Full Load Amps | HP | Length Less Shaft | Motor Enclosure Design | Nameplate RPM | Overall Length | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
056T34D5364 | 6.5" | 56HZ | 13.5-12.4/6.2 | 5 | 11.187" | Open Dripproof | 3450 | 13.5" | €1,077.28 |
