LEESON 056H17E5304 Y603 / 56H17E5304B Explosion Proof Motor, 0.75 HP, 3 Phase, 60 Hz, 230/460 V, 1800 RPM
Get it by Tuesday, Jun 17
€1,219.14 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Vector Motor |
| Ambient Temp. | 40°C |
| Application | Crane |
| Base Type | Rigid Base |
| Bearing Type | Ball |
| Color | Black |
| Conduit Box Position | F3 |
| Duty Cycle | Continuous |
| Efficiency | 82.5% |
| Efficiency Group | Standard |
| Encoder Acceptable | No |
| Encoder Shaft | None |
| Frame | 56C |
| Frame Material | Rolled Steel |
| Frequency | 60 Hz |
| Full Load Amps | 2.4/1.2A |
| Full Load Torque | 2.25 lbs.-ft. |
| Hazardous Location Class | 1 C, D, 2 F, G |
| Hp | 3/4 hp |
| Insulation Class | Class F |
| Insulation Feature | Max Guard Class F |
| Max. Operating Frequency | 120 Hz |
| Max. Rpm | 3600 RPM |
| Motor Enclosure Design | Totally Enclosed Non Ventilated |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | Thermostat |
| Motor Type | Three Phase |
| Mounting Type | Face, Base |
| Nameplate Rpm | 1725 RPM |
| Nema Design | A |
| Number Of Speeds | 1 |
| Overall Length | 13 1/2" |
| Phase | 3 |
| Rpm Range | 1701-1800 RPM |
| Service Factor | 1 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2 1/16" |
| Speed Ratio | 1000:1 |
| Thermal Protection | None |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 230/460V AC |
| Warranty | 3 yrs. |
| Finish | Black |
| Hz | 60 Hz |
| Ins. Class | Class F |
| Max. Ambient Temp. | 104°F |
| Max. Speed | 3600 RPM |
| Motor Application | Crane |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Frame Material | Steel |
| Motor Service Factor | 1 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 82.5% |
| Speed Range | 1000:1 |
| Standards | UL LISTED AND CSA CERTIFIED |
| Torque | 2.25 lbs.-ft. |
| Weight | 38 lbs. |
| Ship weight (kg) | 17.1 |
| Ship height (cm) | 23.16 |
| Ship length (cm) | 40.94 |
| Ship width (cm) | 26.04 |
| HS code | 8501514040 |
| Country of Origin | MX |
| Product | Model | Efficiency Group | Full Load Amps | HP | Nominal Efficiency | Overall Length | Torque | Price | |
|---|---|---|---|---|---|---|---|---|---|
 |
056H17E5301 | Standard | 1.1/.55 | 1/4 | 0.71 | 12 | 0.75 lb.-ft. | €870.96 | |
 |
056H17E5302 | Standard | 1.2/0.6 | 1/3 | 0.745 | 12 | 1 lb.-ft. | €1,021.35 | |
 |
056H17E5303 | Standard | 1.6/0.8 | 1/2 | 0.8 | 12.5 | 1.52 lb.-ft. | €1,101.22 | |
 |
056H17E5305 | Epact | 3.0/1.5 | 1 | 0.84 | 14 | 3 lb.-ft. | €1,335.18 |
