LEESON 056C34F5324 G518 / 56C34F5324J General Purpose Motor, 1 HP, 1 Phase, 60 Hz, 115/208-230V, 3600 RPM
Get it by Tuesday, Jun 17
€509.31 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | General Purpose Motor |
| Ambient Temp. | 40°C |
| Bearing Type | Ball |
| Capacitor Required | No |
| Conduit Box Position | F1 Only |
| Duty Cycle | Continuous |
| Efficiency | 72% |
| Efficiency Group | Standard |
| Frame | 56C |
| Frame Material | Rolled Steel , Steel |
| Frequency | 60 Hz |
| Full Load Amps | 12.4/6.2-6.7A , 12.4/6.7-6.2A |
| Hp | 1 hp |
| Insulation Class | Class B |
| Inverter Rated | No |
| Length Less Shaft | 10 1/4" |
| Max. Ambient Temp. | 104°F |
| Motor Application | General Application |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Face |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Type | Capacitor Start |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 3450 RPM |
| No. Of Speeds | 1 |
| Number Of Speeds | 1 |
| Overall Length | 12 5/16" |
| Phase | 1 |
| Rpm Range | 3001-3600 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2 1/16" |
| Thermal Protection | None |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 115/208-230V AC |
| Warranty | 2 yrs. |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Manufacturers Warranty Length | 2 yrs. |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start |
| Motor Frame Material | Steel |
| Motor Service Factor | 1.15 |
| Motor Thermal Protection | None |
| Nominal Efficiency | 72% |
| Standards | CE, CSA, UL RECOGNIZED |
| Weight | 29 lbs. |
| Ship weight (kg) | 13.05 |
| Ship height (cm) | 23.16 |
| Ship length (cm) | 40.94 |
| Ship width (cm) | 26.04 |
| HS code | 8501406040 |
| Country of Origin | MX |
| Product | Model | Full Load Amps | HP | Hz | Length Less Shaft | Motor Application | Motor Mounting Position | Motor Thermal Protection | Nameplate RPM | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5KCR46MN0093 | 5.8-5.6/2.9-2.8 | 1/2 | 50/60 | - | General Application | All Angle | None | 1725/1425 | €771.07 | |
 |
5KCR49UN0107 | 11.8-11.4/5.9-5.7 | 1 | 50/60 | - | General Application | All Angle | None | 1725/1425 | €977.26 | |
 |
5KC49SN2156X | 16.4/8.2 | 1.5 | 60 | - | Pumps | All Angle | Auto | 3450 | €821.08 | |
 |
5KC32GN25 | 5.4/2.7 | 1/4 | 60 | 8.25" | General Application | Horizontal | None | 1725 | €380.29 | |
 |
5KC33FN31 | 5.6/2.8 | 1/3 | 60 | 8.5" | General Application | Horizontal | None | 3450 | €338.31 | |
 |
5KC35MN73 | 6.0/3.0 | 1/3 | 60 | 8.875" | General Application | Horizontal | None | 1725 | €439.55 | |
 |
5KC42GN0018 | 8.6/4.3 | 1/2 | 60 | 8.875" | General Application | Horizontal | None | 1725 | €507.46 |
