LEESON 056C17D2101 X601 / 56C17D2101L Motor, 0.33 HP, 1 Phase, 60 Hz, 115/208-230V, 1800 RPM
Get it by Tuesday, Jun 17
€467.94 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Direct Drive Blower Motor |
| Bearing Type | Ball |
| Body Dia. | 5 5/8" |
| Capacitor Included | Yes |
| Capacitor Required | No |
| Conduit Box Location | Exterior |
| Conduit Box Position | F1 Only |
| Duty Cycle | Continuous |
| Frame | 56Z |
| Frequency | 60 Hz |
| Full Load Amps | 5.8/2.8-2.9A |
| Full Load Efficiency | 52% |
| Hp | 1/3 hp |
| Insulation Class | Class B |
| Length Less Shaft | 8 3/4" |
| Max. Ambient Temp. | 40°C |
| Motor Application | HVAC/R |
| Motor Enclosure Design | Open Dripproof |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Shaft Design | Threaded |
| Motor Shaft Rotation | CCWSE |
| Motor Sub Application | Direct Drive Fan/Blower |
| Motor Thermal Protection | Automatic |
| Motor Type | Capacitor Start |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 1725 RPM |
| No. Of Speeds | 1 |
| Nominal Efficiency | 52% |
| Number Of Shafts | 1 |
| Number Of Speeds | 1 |
| Overall Length | 14 1/16" |
| Phase | 1 |
| Resilient Ring Dia. | 2 1/2" |
| Ring To Ring Center | 8 7/16" |
| Rpm Range | 1701-1800 RPM |
| Service Factor | 1.35 |
| Shaft Dia. | 5/8" |
| Shaft Length | 5 11/16" |
| Shaft Type | Threaded |
| Thermal Protection | Automatic |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 115/208-230V |
| Warranty | 1 yr. |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Manufacturers Warranty Length | 1 yr. |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start |
| Motor Service Factor | 1.35 |
| Standards | CSA (LR2025), UL (E6312) |
| Weight | 20 lbs. |
| Ship weight (kg) | 9 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 50.5 |
| Ship width (cm) | 26.04 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Body Dia. | Frame | Full Load Amps | HP | Length Less Shaft | Nominal Efficiency | Overall Length | Ring to Ring Center | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
056C17D2102 | 5.625" | 56Z | 8.0/4.0-4.0 | 1/2 | 9.75" | 62.0% | 15 1/16" | 9.437" | €575.37 | |
 |
056C17D5346 | 6.5" | 56 | 12.0/5.8-6.0 | 3/4 | 9.437" | 66.0% | 15" | 9.125" | €723.53 |
