LEESON 056B17F5310 G396 / 56B17F5310J Pressure Washer Motor, 1.50 HP, 1 Phase, 60 Hz, 115/208-230V, 1800 RPM
Get it by Tuesday, Jun 17
€834.03 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Definite Purpose Motor |
| Ambient Temp. | 40°C |
| Assembly | F3 |
| Bearing Type | Ball |
| Body Dia. | 7 2/5" |
| Bolt Circle Dia. | 5 7/8" |
| Conduit Box Location | Exterior |
| Conduit Box Position | F3 |
| Duty Cycle | Continuous |
| Frame | 56HC |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 13.6/6.8-7.5A |
| Hp | 1 1/2 hp |
| Insulation Class | Class B |
| Length Less Shaft | 11.938" |
| Max. Ambient Temp. | 40°C |
| Motor Application | Pressure Washer |
| Motor Bearings | Ball |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | Selective Clockwise |
| Motor Thermal Protection | Manual |
| Mounting Type | C Face, Rigid Base |
| Nameplate Rpm | 1725 RPM |
| Nema Design | None |
| Nominal Efficiency | 81.5% |
| Number Of Speeds | 1 |
| Orientation | Horizontal |
| Overall Height | 9" |
| Overall Length | 13.812" |
| Phase | 1 |
| Power | 1.12 kW |
| Service Factor | 1.15 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2 1/8" |
| Thermal Protection | Manual |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 115/208-230V AC |
| Height | 9" |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Motor Design | Capacitor Start/Run |
| Motor Frame Material | Steel |
| Motor Service Factor | 1.15 |
| No. Of Speeds | 1 |
| Standards | CE MARK, CSA CERTIFIED, UL RECOGNIZED |
| Weight | 45 lbs. |
| Ship weight (kg) | 20.25 |
| Ship height (cm) | 24.77 |
| Ship length (cm) | 49.05 |
| Ship width (cm) | 28.42 |
| HS code | 8501406040 |
| Country of Origin | MX |
| Product | Model | Assembly | Frame | Full Load Amps | HP | kW | NEMA Design | Rotation | RPM | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
056B34F5312 | F3 | 56HC | 17.5/8.7 | 2 | 1.50 | GENERAL DUTY | SELECTIVE CW | 3600 | €866.14 | |
 |
056C17F5955 | F1 ONLY | 56C | 11/5.4-5.5 | 3/4 | 0.56 | NO DESIGN CODE | SELECTIVE CCW | 1800 | €700.07 |
