| Item | Socket Head Cap Screw |
| Drive Size | 1/8" |
| Drive Type | Hex Socket |
| Finish | Black Oxide |
| Hardness | Rockwell C38-C43 |
| Head Dia. | 0.361" |
| Head Height | 0.101" |
| Head Type | Button |
| Length | 5/8" |
| Material | Steel |
| Min. Tensile Strength | 180000 psi |
| System Of Measurement | Imperial |
| Temp. Range | -20°F to +400°F |
| Thread Direction | Right Hand |
| Thread Length | 5/8" |
| Thread Size | #10-24 |
| Thread Style | Fully Threaded |
| Thread Type | Coarse |
| Combined Material & Grade | Grade Alloy Steel |
| Dimensional Standards | ASME B18.3 |
| Display Qty | 100 |
| Head Diameter | 0.361" |
| Material Quality Standards | ASTM A574 |
| Material Type | Steel |
| Maximum Temperature | 400°F |
| Minimum Temperature | -20°F |
| Minimum Thread Length | 5/8" |
| Screw Length | 5/8" |
| Tensile Strength | 180000 psi |
| Thread Fit | 3A |
| Ship weight (kg) | 0.23 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 8.89 |
| Ship width (cm) | 5.59 |
| HS code | 7318156040 |
| Country of Origin | US |
