JOHNSON CONTROLS VG18A5KS HVAC Control Ball Valve, 3-Way, 46 Coefficient of Volume, 2 1/2 Inch Connection Size
Get it by Tuesday, Jun 17
€1,210.16 /unit
Add To Cart
Request a Quote
Payment
Get it by Tuesday, Jun 17
Payment
| Item | Ball Valve |
| Actuator Control Pressure - Maximum | Not Applicable |
| Actuator Control Pressure - Minimum | Not Applicable |
| Actuator Control Signal | Not Applicable |
| Actuator Input Voltage | Not Applicable |
| Actuator Return Action | Not Applicable |
| Actuator Type | Not Applicable |
| Application | Control Of Hot/Chilled Water |
| Ball Material | Stainless Steel |
| Body Material | Brass |
| Close Off Pressure | 50 psi |
| Close-off Pressure | 50 psi |
| Coefficient Of Volume | 46 |
| Connection Size | 2 1/2" |
| Connection Type | Flanged |
| Depth | 13" |
| Disk Material | Polyphthalamide Resin |
| Flow Characteristic | Equal Percentage, Linear |
| For Use With | Mfr. No. M9000 , RP_Mfr No. M9000 |
| Height | 13" |
| Includes Actuator | Actuator Not Included |
| Includes Characterizing Disk | Disk Included |
| Leakage Rate | 1% |
| Material | Brass, Stainless Steel |
| Max. Water Temp. | 284°F |
| Number Of Ways | 3 |
| Overall Depth | 13" |
| Overall Height | 13" |
| Overall Length | 11" |
| Port Connection Size | 2 1/2" |
| Port Connection Type | Flanged |
| Port Types Included | Bypass, Control |
| Rangeability | 5001 |
| Safe Working Water Pressure | 250 psi |
| Safe Working Water Psi | 250 psi |
| Specific Valve Action | Stem Down To Close |
| Stem Material | Stainless Steel |
| Trim Material | Stainless Steel |
| Valve Only/actuator Included | Valve Only |
| Valve Style | Mixing |
| Width | 11" |
| Ship weight (kg) | 10.8 |
| Ship height (cm) | 33.02 |
| Ship length (cm) | 27.94 |
| Ship width (cm) | 27.94 |
| Country of Origin | MX |
| Model | Coefficient Of Volume | Connection Size | Depth | Height | Item | Width | Price | |
|---|---|---|---|---|---|---|---|---|
| VG18A5GS | 47 | 2.5" | 11.437" | 7" | H VAC Control Ball Valve | 9.5" | €1,046.28 | |
| VG18A5GT | 74 | 2.5" | 11.437" | 7" | H VAC Control Ball Valve | 9.5" | €1,046.28 | |
| VG18A5GU | 117 | 2.5" | 11.437" | 7" | H VAC Control Ball Valve | 9.5" | €1,046.28 | |
| VG18A5HT | 74 | 3" | 12.25" | 7.5" | H VAC Control Ball Valve | 10" | €1,299.35 | |
| VG18A5HU | 134 | 3" | 12.25" | 7.5" | H VAC Control Ball Valve | 10" | €1,299.35 | |
| VG18A5HV | 176 | 3" | 12.25" | 7.5" | H VAC Control Ball Valve | 10" | €1,331.65 | |
| VG18A5HW | 211 | 3" | 12.25" | 7.5" | H VAC Control Ball Valve | 10" | €1,306.39 |
