| Item | Valve |
| Actuation Mechanism | Temperature |
| Body Material | Cast Iron |
| Bulb Diameter | 11/16" |
| Bulb Length | 10" |
| Bypass Orifice Diameter | 0.1" |
| Bypass Plug Type | Removable |
| Capillary Length | 6 ft. |
| Capillary Material | Nylon |
| Capillary Type | Armored |
| Disc Material | Buna-N |
| Flow Rate - Maximum | 155 GPM |
| For Media | Water/Glycol |
| For Media State | Liquid |
| For Refrigerant Type | R-134A, R-502 |
| For Repair Kit - Manufacturer Model Number | STT18A-600R |
| Internal Parts Material | Aluminum Bronze |
| Maximum Operating Pressure | 150 psi |
| Number Of Ways | 3 |
| Opening Point Adjustment | Adjustable |
| Opening Temperature - Maximum | 160°F |
| Opening Temperature - Minimum | 115°F |
| Operating Temperature - Maximum | 170°F |
| Orientation | Vertical |
| Overall Height | 10 1/2" |
| Overall Length | 6 5/8" |
| Overall Width | 6" |
| Pipe Connection Size | 2" |
| Pipe Connection Type | NPT |
| Product Type | Pressure Regulating Valve |
| Replacement Cartridge - Manufacturer Model Number | SET29A-632R |
| Specific Valve Action | Opens on Rise |
| Ship weight (kg) | 12.15 |
| Country of Origin | MX |
