| Item | Pressure Control |
| Application | Low Limit |
| Body Finish | Baked Enamel |
| Body Material | Steel |
| Element Type | Diaphragm |
| Number Of Mounting Holes | 2 |
| Pressure Connection Type | Barb |
| Pressure Differential Adjustability | Adjustable |
| Pressure Range Adjustability | Adjustable |
| Pressure Setting | Low |
| Pressure Type | Differential |
| Switch Action | Open On Rise |
| Time Delay Setting | Not Applicable |
| Body Material Finish | Baked Enamel |
| Contact Form | DPST |
| Maximum Operating Temperature | 140°F |
| Minimum Operating Temperature | 32°F |
| Mounting Hole Diameter | 1/4" |
| Mounting Type | Universal |
| Output Current | 12A |
| Overall Depth | 2 3/8" |
| Overall Height | 3 1/4" |
| Overall Width | 4" |
| Pressure Connection Size | 1/4" |
| Pressure Differential | 1.5 psi to 20 psi |
| Pressure Differential - Maximum | 20 psi |
| Pressure Differential - Minimum | 1.5 psi |
| Pressure Range - Maximum | 30 psi |
| Pressure Range - Minimum | 3 psi |
| Process Connection | 1/4" Barb |
| Product Type | Low Pressure Control |
| Rated Voltage | 120/208/240/277V AC |
| Rated Voltage Range | 12-120/208-240/277-600V AC |
| Series | P67 Series |
| Ship weight (kg) | 0.9 |
| Ship height (cm) | 8.26 |
| Ship length (cm) | 6.03 |
| Ship width (cm) | 10.16 |
| Country of Origin | MX |
