JOHNSON CONTROLS P-3800-1 Reset Volume Controller 13 - 25 Psi

Item: AF6YZVModel: P-3800-1Cross Ref: 20RG02

See variants (1)

In Stock

Get it by Tuesday, Jun 17

€328.82 /unit

Add To Cart

Request a Quote

Payment

Product Specifications:

Item	Reset Volume Controller
Air Consumption	0.019 SCFM , 25 SCIM
Air Inlet Size	3/8"
Air Inlet Type	Barb
Air Pressure	13 psig to 25 psig
Application	Cooling, Heating
Color	Black
Controller Type	Direct Acting, Reverse Acting
Depth	6.406"
Height	4.703"
Housing Color	Black
Housing Material	Noryl
Includes	Mounting Bracket
Material Of Construction	Noryl
Max. Air Pressure	25 psi
Minimum Air Pressure	13 psi
Mounting Orientation	Horizontal, Vertical
Reset Pressure Band	3 psig to 10 psig
Reset Start Point Factory Setting	8 psi
Reset Start Point Maximum Setting	10 psi
Reset Start Point Minimum Setting	3 psi
Signal Pressure - Maximum	10 psig
Type	Direct Acting, Reverse Acting
Width	568567"
Air Consumption @ 20 Psi	25 SCIM
Controller Action	Direct/Reverse Acting
Damper Action	Normally Open or Normally Closed
Maximum Operating Temperature	85°F
Maximum Setpoint Range	0.15 in. wg to 3.2 in. wg
Maximum Signal Pressure	10 psig
Minimum Operating Temperature	60°F
Minimum Setpoint Range	0 to 1.6 in. wg
Output Pressure Capability	20 psig to Supply Pressure
Output Sensitivity	2.25 psi/0.01 in. wc
Reset Start Point Range	3 psi to 10 psi
Series	3800 Series
Standards	ROHS COMPLIANT
Thermostat Required For Cooling	Direct/Reverse Acting
Thermostat Required For Heating	Direct/Reverse Acting
Weight	1 lbs.
