| Item | Zone Valve |
| Actuator Control Pressure - Maximum | Not Applicable |
| Actuator Input Voltage | Not Applicable |
| Actuator Return Action | Spring Return |
| Actuator Type | Not Applicable |
| Cartridge Material | Not Applicable |
| Close-off Pressure | 25 psi |
| Configuration | Tee |
| Depth | 1 3/4" |
| Description/special Features | Valve, 3 Way, High Temp, On/Off, Sweat 1/2 |
| For Use With | J Series Actuators |
| Frame Material | Brass |
| Gasket Material | Viton |
| Height | 2 5/8" |
| High Pressure Closeoff | 30 , 30 psi |
| Includes | Valve Only |
| Includes Actuator | Actuator Not Included |
| Installation Orientation | Horizontal |
| Max. Temp. | 250°F |
| Min. Actuator Control Pressure | Not Applicable |
| Overall Depth | 1 3/4" |
| Overall Height | 2 5/8" |
| Overall Length | 2 5/8" |
| Port Connection Size | 1/2" |
| Port Connection Type | Sweat |
| Safe Working Steam Pressure | 15 psi |
| Safe Working Steam Psi | 15 psi |
| Safe Working Water Psi | 300 psi |
| Stem Material | Brass |
| Union Connection Size | Not Applicable |
| Valve Style | Diverting, Mixing |
| Width | 2 5/8" |
| Actuator Control Signal | On, Off |
| Body Material | Brass |
| Body Pattern | Three-Way |
| Compatible With Series | Series J |
| Cv Flow Rate | 4 |
| Fluid Service | Steam, Water, Water Glycol Solution to 50% |
| Fluid Temperature - Maximum | 250°F |
| Fluid Temperature - Minimum | 32°F |
| Valve Action | Normally Open, Normally Closed |
| Ship weight (kg) | 0.32 |
| Ship height (cm) | 6.67 |
| Ship length (cm) | 4.45 |
| Ship width (cm) | 6.67 |
| HS code | 8481809050 |
| Country of Origin | US |
| Product | Model | Coefficient Of Volume | Connection Type/size | Height | Type | Width | Price | |
|---|---|---|---|---|---|---|---|---|
 |
JM2212 | 2 | Sweat 1/2" | 1.875" | 2 Way, Modulating Body | 2.62" | €92.43 | |
|
JM2222 | 2 | (F)NPT 1/2" | 1.875" | 2 Way, Modulating Body | 2.62" | €110.67 | |
|
JM2223 | 4 | (F)NPT 1/2" | 1.875" | 2 Way, Modulating Body | 2.62" | €99.20 | |
 |
JM2322 | 2 | (F)NPT 3/4" | 1.875" | 2 Way, Modulating Body | 2.75" | €151.71 | |
|
JM2327 | 7.5 | (F)NPT 3/4" | 1.875" | 2 Way, Modulating Body | 2.75" | €151.71 | |
 |
JM3221 | 1 | (F)NPT 1/2" | 2.625" | 3 Way, Modulating Body | 2.62" | €134.40 | |
|
JM3222 | 2 | (F)NPT 1/2" | 2.625" | 3 Way, Modulating Body | 2.62" | €128.17 |
